Combining navigation on the easySlider jQuery plugin

slider

Today, I was putting together a proof-of-concept for a new website design that included a media ‘slider’ on the home page. I did a bit of searching and came across the Easy Slider 1.7 plugin which uses jQuery to simplify this task. Score! We love jQuery here at TPI because it takes heavy-coding Javascript tasks and makes them really simple to accomplish and usually more interactive and fun.

This plugin seemed to have all we needed except one thing. There was a choice in navigation between arrows left and right (previous and next) OR numeric/individual item navigation below. (For this case, we’ll use actual ‘Sliders’ as our representation of the easySlider. Hungry yet?)

Navigation illustration

For the design we’re envisioning, both systems needed to be utilized. It seemed like a simple fix and I set about combining both  navigation types to show up at the same time. Problem. For some reason, the next/previous buttons weren’t behaving properly when you used the numeric navigation below to choose an item! If you clicked on an item in the numeric nav, the next button would inexplicably send the gallery zooming off into space and then slowly return to the first item in the list.

How do we fix this!? Good ol’ scheming and know-how to the rescue! I’ll give you the quick-and-dirty since I’m pretty sure that’s what you’re interested in, anyway.

First, to show both navigations, go into easySlider1.7.js and find this part:

if(options.controlsShow){
var html = options.controlsBefore;
if(options.numeric){
html += '<ol id="'+ options.numericId +'"></ol>';
} else {
if(options.firstShow) html += '<span id="'+ options.firstId +'"><a href=\"javascript:void(0);\">'+ options.firstText +'</a></span>';
html += ' <span id="'+ options.prevId +'"><a href=\"javascript:void(0);\">'+ options.prevText +'</a></span>';
html += ' <span id="'+ options.nextId +'"><a href=\"javascript:void(0);\">'+ options.nextText +'</a></span>';
if(options.lastShow) html += ' <span id="'+ options.lastId +'"><a href=\"javascript:void(0);\">'+ options.lastText +'</a></span>';
};

html += options.controlsAfter;
$(obj).after(html);
};

And change it to this:

if(options.controlsShow){
var html = options.controlsBefore;
if(options.numeric){
html += '<ol id="'+ options.numericId +'"></ol>';
if(options.firstShow) html += '<span id="'+ options.firstId +'"><a href=\"javascript:void(0);\">'+ options.firstText +'</a></span>';
html += ' <div id="arrows"><span id="'+ options.prevId +'"><a href=\"javascript:void(0);\">'+ options.prevText +'</a></span>';
html += ' <span id="'+ options.nextId +'"><a href=\"javascript:void(0);\">'+ options.nextText +'</a></span></div>';
if(options.lastShow) html += ' <span id="'+ options.lastId +'"><a href=\"javascript:void(0);\">'+ options.lastText +'</a></span>';
} else {
if(options.firstShow) html += '<span id="'+ options.firstId +'"><a href=\"javascript:void(0);\">'+ options.firstText +'</a></span>';
html += ' <span id="'+ options.prevId +'"><a href=\"javascript:void(0);\">'+ options.prevText +'</a></span>';
html += ' <span id="'+ options.nextId +'"><a href=\"javascript:void(0);\">'+ options.nextText +'</a></span>';
if(options.lastShow) html += ' <span id="'+ options.lastId +'"><a href=\"javascript:void(0);\">'+ options.lastText +'</a></span>';
};

html += options.controlsAfter;
$(obj).after(html);
};

Then find this part:

if(options.numeric){
for(var i=0;i<s;i++){
$(document.createElement("li"))
.attr('id',options.numericId + (i+1))
.html('<a rel='+ i +' href=\"javascript:void(0);\">'+ (i+1) +'</a>')
.appendTo($("#"+ options.numericId))
.click(function(){
animate($("a",$(this)).attr('rel'),true);
});
};
} else {
$("a","#"+options.nextId).click(function(){
animate("next",true);
});
$("a","#"+options.prevId).click(function(){
animate("prev",true);
});
$("a","#"+options.firstId).click(function(){
animate("first",true);
});
$("a","#"+options.lastId).click(function(){
animate("last",true);
});
};

And change it to this:

if(options.numeric){
for(var i=0;i<s;i++){
$(document.createElement("li"))
.attr('id',options.numericId + (i+1))
.html('<a rel='+ i +' href=\"javascript:void(0);\">'+ (i+1) +'</a>')
.appendTo($("#"+ options.numericId))
.click(function(){
animate($("a",$(this)).attr('rel'),true);
});
};
$("a","#"+options.nextId).click(function(){
animate("next",true);
});
$("a","#"+options.prevId).click(function(){
animate("prev",true);
});
$("a","#"+options.firstId).click(function(){
animate("first",true);
});
$("a","#"+options.lastId).click(function(){
animate("last",true);
});
} else {
$("a","#"+options.nextId).click(function(){
animate("next",true);
});
$("a","#"+options.prevId).click(function(){
animate("prev",true);
});
$("a","#"+options.firstId).click(function(){
animate("first",true);
});
$("a","#"+options.lastId).click(function(){
animate("last",true);
});
};

NOW, to make it work properly (and here’s the kicker), parseInt!!!!!

Find the ‘animate’ function (~line 140):

function animate(dir,clicked){
if (clickable){
clickable = false;
var ot = t;
switch(dir){
case "next":
t = (ot>=ts) ? (options.continuous ? t+1 : ts) : t+1;
break;
case "prev":
t = (t<=0) ? (options.continuous ? t-1 : 0) : t-1;
break;
case "first":
t = 0;
break;
case "last":
t = ts;
break;
default:
t = dir;
break;
};

And insert this itttty bitty little parseInt:

function animate(dir,clicked){
if (clickable){
clickable = false;
var ot = t;
t = parseInt(t);
switch(dir){
case "next":
t = (ot>=ts) ? (options.continuous ? t+1 : ts) : t+1;
break;
case "prev":
t = (t<=0) ? (options.continuous ? t-1 : 0) : t-1;
break;
case "first":
t = 0;
break;
case "last":
t = ts;
break;
default:
t = dir;
break;
};

Thats it! Wow, that seemed a lot harder than it was. We figured out that the two navigations were treating the current item differently (one as an integer, one as a string – who knew!) so basically we’re just telling them all to be integers so both methods will work the same.

For reference, here’s another little proof of concept we drew up. Sliders. Get it? We’re hilarious, i know. (click the pickles OR the ketchup. CRAZY!) easySlider plugin ‘Sliders’ demo

10 thoughts on “Combining navigation on the easySlider jQuery plugin

  1. Thanks for the code tip. Debugging code embodies the highs and lows… it can be the most unnerving and daunting task ever, but conversely thrilling when you get it to work.

    Plus the sliders… now that’s just showing off.

  2. Nice hack. In the second change you could probably just remove the ‘else,’ and probably do something similar in the first change if you didn’t care that the #arrows div gets added for nonnumeric. It can be a hard choice to modify a plugin’s code; they usually have a lot of extra code to make them work for whatever settings you give them. Also, if you ever want to update them (unlikely in this case), it can be difficult to merge your code with the new version. I think you made the right choice with this one though, and I love the demo.

  3. hey, nice tip!
    but one question: i’m working on a portfolio right now and i combined 2 sliders with the arrows, so that both slideshows slide when you go on prev and next. the problem is that i wanna combine it with the numeric like when i jump from page 1 to 4, both sliders should be jump as well. Is it possible?

  4. Awesome hack. Just wondering if there is a way to reverse the order of the numbers, in case you want to float them to the right?
